PalPilot manufactures standard and custom cable and wire harness products. Our fully integrated in-house design, tooling, and manufacturing utilize state-of-the-art, fully automated processes. Enabling us to provide world-class quality, superior pricing, and unique flexibility to the interconnect market.
We are your One-Stop Solutions Provider, where quality meets excellence.
Our team recognizes the importance of supply and demand; each task is carefully executed. The significance of our component supply chain demonstrates our ability to adapt to the ever-changing dynamics of the electronics industry. Learn more about our Component Supply Chain service.
The Interconnect Division of PalPilot International Corp. has introduced a USB 3.1 Type-C to USB Type-C Gen 2 (10Gbps) Full Featured (with E-Marker) Cable Assembly. Refer to PalPilot p/n USB-UB-001-033 Rev X7. The USB-IF certified TID number is 5,200,000,581.
Applications include Notebooks, Tablets, Mobile Phone, Personal Storage, Network/Server, Telecom, Industrial, Security, and Portable Charging Devices.
The USB 3.1 cable features USB-IF certified plugs on each end. This new cable and connector support USB performance at SuperSpeed USB 10Gbps (USB3.1) and USB Power Delivery 2.0 capacity 3A@20V up to 100W. Transport of both USB signals and PCIe or DisplayPort signals on the same cable.
Other features include 970mm length, 4.8+/-0.2mm OD, Full Featured E-Marker for Cable ID. The Type-C plugs are sealed in metal enclosures, then over molded, for best EMI performance. The cable features reversible plug orientation and cable direction.
All models support Operating Temperature range of -40˚C to +85˚C. All components are RoHS, REACH, Conflict Mineral, UL Compliant.
For standard product details, please refer to online data sheets, or visit www.palpiot.com or contact customer service at 714-460-0718, Tustin, CA., or 408-855-8866, Milpitas CA.
The Interconnect Division of PalPilot International Corp., has introduced four new cable assemblies, designed to meet HDMI 1.4b and HDMI 2.0 Premium cable requirements.
Applications include PC Monitors, Video Projectors, Ultra HDTV’s, Set-top Boxes and HDMI Displays.
HDMI 1.4b Category 2 cable features include 19 pin A Type or C Type male plug on cable ends, 5.5mm cable diameter OD’s, and 1.50M to 2.44M cable lengths. Maximum pixel clock rate is 340 MHz, and Max TMDS throughput per channel is 3.4Gbit/s or 10.2 Gbit/s total.
HDMI 2.0 premium cable features include 19 pin A Type male plugs on cable ends, 3.5mm to 4.5mm cable diameter OD’s (industry’s smallest) and 1.00M to 1.50M cable lengths. Maximum pixel clock rate is 600MHz, and Max TMDS throughput per channel is 6 Gbit/s or 18 Gbit/s total.
Other features include slim connector shell and overmold, for better EMI and ESD shielding design. Some models support additional HDMI Ethernet Channel (HEAC).
All models support Operating Temperature range of 0˚C to +50˚C. All components are RoHS, REACH, Conflict Mineral, UL Compliant.
For standard product details, please refer to online data sheets, or visit www.palpilot.com or contact customer service at 714-460-0718, Tustin, CA., or 408-855-8866, Milpitas CA.
